 項目Ltem        型號Model   |
 DKTL30   |
 DKTL45   |
 DKTL60   |
|
 產量(稻谷混合物)(Kg/h)putput(mixture of paddy and cereal)(Kg/h)   |
 600-900   |
 900-1200   |
 1200-1400   |
|
 次糧分離效率(%)Secongary grain separtion officency(%)   |
 ≥90   |
 ≥90   |
 ≥90   |
|
 稻谷含飽滿粒(粒/100kg)Paddy including plump granule (granule/100kg)   |
 ≤20   |
 ≤20   |
 ≤20   |
|
 提取物含稻殼(%)Extracted substance including rice hull (%)   |
 ≤7   |
   ≤7   |
 ≤7   |
|
 進口風量(m³/h)Outlet blast volume(m³/h)   |
 2500-3600   |
 3600-5000   |
 5500-7000   |
|
 精選室補風量 (m³/h)Choice compensational blast volume (m³/h)   |
 800-900   |
 1000-1200   |
 1200-1800   |
|
 出口風量(m³/h)Outlet blast volume(m³/h)   |
 3300-4500   |
 4600-6200   |
 6700-8800   |
|
 壓力損失 (Pa)Pressure loss(Pa)   |
 ≤400   |
 ≤500   |
 ≤500   |
|
 進口(寬×高) Inlet(W×H)(mm)   |
 300×600   |
 450×160   |
 600×160   |
|
 出口(寬×高) Outlet(W×H)(mm)   |
 300×250   |
 450×250   |
 600×250   |
|
 機重(Kg) Weight(Kg)   |
 89   |
 138   |
 168   |
|
 外型尺寸[長×寬×高](mm)Outine dimension (L×W×H)(mm)   |
 1540×354×1700   |
 1540×504×1820   |
 1540×654×1920   |
|
 所配礱谷機稻谷加工量(t/h)the matched rice huller paddy processing capacity(t/h)   |
 2-2.5   |
 4-4.8   |
 5.5-6.5   |
|
 所配礱谷機膠輥規(guī)格the matched rice huller glue roller specification   |
 Ф10"(Ф250mm)   |
 Ф14"(Ф360mm)   |
 Ф102"(Ф250×2)   |
